Beam Load Cell-SDC

Beam Load Cell-SDC

Download bijlagen:

Compact digital beam load cell for dynamic weighing, web tension measurement, process weighing, force measurement and general industrial weighing. This load cell is a short version of the SD beam load cell. It is produced in stainless steel and laser welded (IP68).



Type: SDC

Capacity (Emax): 1, 2, 5, 10, 20, 30, 50, 100 kg

Accuracy: Industrial 0.10%, Precision 0.05%, High Precision 0.025%

Overload tolerance: 500% at 2kg, 200% at 100kg capacity



Special features:

  • Short version of SD load cell
  • Stainless steel
  • Made in Denmark
  • Robust capacitive technology
  • Patented high reliability capacitive sensor
  • High tolerance of up to 1.000% overload
  • Hermetically sealed to IP68
  • Laser welded
  • High accuracy, High resolution
  • Small deflection at rated capacity
  • Capacity (Emax): 1, 2, 5, 10, 20, 30, 50, 100kg
  • Accuracy: Industrial 0.10%, Precision 0.05%, High Precision 0.025%
  • High resonance frequency (spring rate) for rapid dynamic weighing
  • Digital filters
  • Cable length up to 100meters
  • Calibration independent of cable length
  • Easy mechanical and electrical installation
  • Withstands welding voltages and ESD
  • Load cell cable replaceable

Options:

  • Load cell cable length 10, 20, 50 or 100meters
  • Special Teflon load cell cable available for very high temperature (can be used up to 100 degrees Celsius)
  • Special PE load cell cable available for freezing low temperature (can be used down to -50 degrees Celsius)
